Potmeter Bourns 500K longshaft - LOG

Art.nr: 05-500XL-1

kr.165,-

Antall:

Bourns

12 På lager

Informasjon

Audiotaper (LOG) 500K potmeter med lang bøssing (20 mm) fra Bourns.

Taper: Audio (log)
Standard Resistance Tolerance: ±20% TRS
Contact Resistance Variation: 1% maximum
Moisture resistance: ±20% TRS
Operating Temperature: -10°C to °C
Power Rating: 0.25W
Maximum Operating Voltage: 250V
Mechanical Angle: 300° ±5°
Rotational Torque: 29 g-cm typical
Stop Strength: 8 kg-cm min.
Rotational Life: 100,000 cycles min.
Soldering Condition: Manual Soldering: 300°C within 3 sec. Wave Soldering: 260°C within 3 sec.
Hardware: One flat washer and mounting nut supplied per potentiometer with bushing

Features:
Low torque
Carbon element
Plain or Knurled shaft option
ESD wave washer
Metal bushing
Metal shaft
Conductive polymer element
Singleturn
RoHS Compliant
